“Dragonfly-shaped” series is the earliest multipoint lock handle design.

In order to satisfy different needs, handle can be with button, without button or with key. Handle can also be with different base shape and measurement.

Multipoint lock handle with suitable number of locking points can shut the window tighter than dual lock or cam handle.

For child safety, handle with button or handle with keys can be a good choice.

Multipoint Lock Handle – “Dragonfly Tail”-shaped Series

Product Code
Two screw holes distance (center to center)
Base 43MM 50MM 55MM
Triangular-shaped Without Button CL17P
With Button CL17
With Key CL17K
AC Triangular-shaped Without Button CL17P-50
With Button CL17-50
With Key CL17K-50
Rectangular-shaped Without Button MSTW
With Button MST
With Key MSTK
Long Rectangular-shaped Without Button MSTL
With Button MSTLOB
With Key MSTLK
Direct Mount Without Button MSTWHF MST-FM MSTWCL
With Button MSTP-FM MSTCL 及 MSTP
With Key MSTK-FM
Read More

– Use M5 screws
– One multipoint lock handle tolerates four locking points maximum.
– Please pay attention to screw holes distance of multipoint lock handle when choosing gear box.

Zinc Alloy

Continuous opening and closing 50,000 cycles test report of “CL17” is available upon request.

Hong Kong 9811381.6M002, 0010236.2

– Do not use strong detergent (i.e. Blench / Alcohol) or erosive penetrant for cleaning purposes.
