HYLS is suitable for side hung window use. This series takes larger loading than “HHMS” series friction hinges.

Durability of the hinge has been proven by opening and closing test 50,000 times.

The hinges have been tested against the requirements of British Standard BS6375-2:2009.

HYLS

Loading Opening
Product Code Product Description KG (-5°/+0°) Catalogue
HYLS12 12″ Stainless Steel Friction Hinge – HYLS Series 60 90°
HYLS14 14″ Stainless Steel Friction Hinge – HYLS Series 68 90°
HYLS16 16″ Stainless Steel Friction Hinge – HYLS Series 83 90°
HYLS18 18″ Stainless Steel Friction Hinge – HYLS Series 82 90°
Read More
  • To maximize the functionality of the hinges, must install with stainless steel plate
  • Installation Guideline
  • All screw holes should be mounted with proper screws.
  • Must pay attention to space requirement when installing the hinge.
Grade 304 stainless steel

Test report is available upon request.

China 201710712835.3, 201710713594.4, 201920981460.5 | Hong Kong HK1247974, HK1245865

– All screw holes should be mounted with proper screws.
– Must pay attention to space requirement when installing the hinge. (Please refer to “Installation Guideline”)
– Must pay attention to the maximum tolerable loading of the hinge. (Please refer to “Catalogue”)
– Do not use strong detergent (i.e. Blench / Alcohol) or erosive penetrant for cleaning purposes.
